Highlight:
Modular Design Bailey Trestle Bridge Piers
, Bailey Trestle Bridge Piers And Deck
, Modular Bailey Trestle Bridge Piers Deck
Product Name: |
Bailey Bridge Pier |
Loading Standard: |
Hl93/Ha+20hb/T44/Class A/B/MLC110/dB24 |
Steel Grade: |
S355/ S460/Gr 55c/Gr350/Gr50/Gr65/GB355/460 |
Stress Characteristics: |
Truss Bridge |
Application: |
Over Water Bridge, Tractor Bridge, Pontoon, Footbridge, Public Iron Dual Purpose Bridge, Highway Bridge |
Standard: |
AISI, ASTM, BS, DIN, GB, JIS |
Bailey Trestle Bridge Piers And Deck Modular Design On Site Fast Construction
Introduction of Bailey Type Trestle Bridge And Platform
The Bailey trestle bridge is composed of standardized, prefabricated steel panels and components that can be easily assembled on-site.
These modular elements include chords, web members, transoms, and bracing, which can be quickly connected to form the bridge structure.
Applications of Bailey Type Trestle Bridge And Platform
Temporary Bridge Construction:
The Bailey Trestle Bridge is commonly used as a temporary bridge solution, especially in situations where a permanent bridge is under construction or in need of repair.
The trestle design, with its vertical support towers, allows the Bailey Trestle Bridge to span longer distances and accommodate greater loads compared to a standard Bailey bridge.
This makes it suitable for use in areas with wider rivers, ravines, or other significant obstructions that require a longer span.
Features of Bailey Type Trestle Bridge And Platform
Rapid Assembly:
The modular design of the Bailey trestle bridge allows for quick and efficient installation, often within a matter of days or even hours.
The bridge can be assembled by a team of trained personnel, without the need for specialized equipment or heavy machinery.
Versatility:
The Bailey trestle bridge can be adapted to span various distances, from 10 meters to over 60 meters, by adding or removing trestle support bays.
The height of the bridge can also be adjusted by adding or removing trestle panels, accommodating different terrain and clearance requirements.
